MIL-PRF-21480/12F(AS)
COOLING AIR INLET
CONFORMING TO
SAE-AS5131-48 PER
SAE-AS5131
GENERATOR DATA
RATED VOLTAGE
120/208V
RATED OUTPUT
40 KVA
PHASE
3
FREQUENCY
380 - 420 Hz
SPEED RANGE
5700-6300 RPM
MAX SPEED FOR REGULATION
8000 RPM
OVERSPEED
9000 RPM
.375-24 UNF-2A
RATED POWER FACTOR
.75 LAG TO 1.0
STEEL STUDS EACH
EFFICIENCY MIN AT RATE LOAD
85%
WITH MS90415-6
MAX WEIGHT
83 LB
NUT PER
OVERHUNG MOMENT - MAX
500 LB IN (MAX)
NASM90415
SHEAR
4000 TO 4600 LB IN
FLEXIBLE DRIVE
NOT REQUIRED
FIGURE 2. M21480/12-2, generator.
2
