MIL-DTL-38195D
Table V. Test schedule. 1/ Continued
Test Method
Requirement Paragraph
First Article
Quality
Sample
(MIL-STD-705 and/or
Inspection
Conformance
Inspection
Test
Test Paragraph)
Test
Number
A
B
C
D
E
Generator Set (continued)
X
--
13
Voltage modulation
X
602.1b; Table II
--
--
14
Voltage and frequency
X
614.1b; 3.9.3.1; Table
regulation
II; Table VI
X
--
Phase balance (voltage)
15
X
508.1d (508.1.2 only);
Table II; Table VI
--
X
Circuit interrupter (short
512.1d (Oscillograph on
16
X
circuit)
First Article only);
3.10.1 Table IV
--
X
17
Circuit interrupter (overload
512.2d; Table IV
X
current)
--
X
Circuit interrupter (over voltage
512.3d; Table IV
18
X
and under voltage)
--
X
Indicating instrument
513.1d; Table IV
X
19
(electrical)
--
X
Under speed protective device
506.1b; Table IV
X
20
--
X
Low oil pressure protective
515.1b; 3.9.2.4;.4.1.2.2
X
21
device
--
X
515.2b; 3.9.2.2;
X
Over-temperature protective
22
4.4.1.2.1
device
--
X
X
507.1d; Table II
23
Phase sequence (rotation)
--
X
X
503.2c; 3.4.1; 3.11.5;
24
Start and stop (remote control)
4.4.1.2.11
--
X
X
3.4.1; 4.4.1.2.4
25
Preliminary check run
--
X
X
26
3.4.1; 3.11; 4.4.1.2.5
Automatic start
--
X
X
27
Normal operation check
3.4.1; 3.4.2; 3.11;
4.4.1.2.6
--
X
X
28
Full load start
3.4.1; 4.4.1.2.7
20
